January 2026 - James Taylor

Consistent, accessible drag-and-drop patterns across cards and lists

We’ve received multiple requests for system-wide guidelines and styles for drag-and-drop interactions. This document provides recommendations for creating an accessible experience, outlines design requirements, and evaluates what functionality should be built into our components versus what should be left to consumers.

While drag and drop can seem straightforward at first glance, it quickly becomes more complex when you consider users who interact with our applications using something other than a mouse.

This section willl explore what a truly accessible drag and drop looks like. That means going beyond basic keyboard support to ensure interactions are understandable for screen reader users, work with other assistive technologies, and conform to WCAG 2.2 success criterion 2.5.7 (Dragging Movements). With no single established best practice, there’s a lot to consider.

The terms “drag and drop” can describe several distinct interactions patterns:

• Moving items between containers, such as kanban / projects boards
• Reordering items with a single container, like sortable lists
• Draging panel edges to adjust dimensions, like adjusting table column header widths
• Free positioning items within a canvas, application windows

I would say the first two use-cases are the most strongly associated with the term and probably the most common with the context of our applications, so I will focus on those.

Here are some accessible codepen examples I have put together:

• Accessible drag and drop sortable list
• Accessible drag and drop card kanban board

Not everyone can reliably perform pointer-based drag interactions. Always provide alternative ways for people using assistive technologies to achieve the same results as drag-and-drop.

When designing these alternative flows, ensure that you:

1. Allow the user to clearly trigger an action or outcome
2. Communicate what action was completed and its result
3. Let the user easily continue to trigger more actions

When designing and building drag-and-drop interfaces, treat drag and drop as an enhancement to the basic alternative flow outlined above. In the examples above, drag and drop can be disabled (by setting the draggable variable to false) and the interface will still function and make sense without it.

Use visible and accessible controls (like buttons, menus, and forms) to make it easy for people using assistive technologies to achieve the same outcomes as a drag operation.

General pattern: buttons and menus

Draggable entities should include a button that triggers an inline menu containing available movement outcomes.

• Movement outcomes can be exposed via a More button (…). The presence of a More button does not remove the requirement for a visible drag handle icon.
• If a draggable entity does not include a More button and movement outcomes are the only actions available, the drag handle icon may be converted into a drag handle menu button that opens an inline menu listing those movement outcomes.
• A draggable entity must have only one action-triggering button. It should not include both a More button (…) and a drag handle menu button—only one of these patterns should be used.
• If a draggable entity does not display a drag handle icon because drag affordance is implied (for example, a draggable card), it should still include a More button (…) to expose movement outcomes.

<div id="wrapper">
  <vwc-card appearance="outlined">
    <div class="container" slot="main">
      <vwc-icon name="reorder-vertical-solid" connotation="accent" size="-6" class="drag-icon"></vwc-icon>
      <div class="content">
        <div class="text">Drag handle always visible</div>
        <vwc-menu placement="bottom-end" auto-dismiss class="action-menu">
          <vwc-button aria-label="More actions" size="condensed" appearance="ghost-light" class="action-menu-button" slot="anchor">
            <vwc-icon name="more-horizontal-solid" slot="icon" connotation="accent" size="-6"></vwc-icon>
          </vwc-button>
          <vwc-menu-item text="Move to top"></vwc-menu-item>
          <vwc-menu-item text="Move up"></vwc-menu-item>
          <vwc-menu-item text="Move down"></vwc-menu-item>
          <vwc-menu-item text="Move to bottom"></vwc-menu-item>
          <vwc-divider></vwc-divider>
          <vwc-menu-item text="Mark as done"></vwc-menu-item>
          <vwc-menu-item text="Delete"></vwc-menu-item>
        </vwc-menu>
      </div>
    </div>
  </vwc-card>

  <vwc-card appearance="outlined">
    <div class="container" slot="main">
      <vwc-menu placement="bottom-start" auto-dismiss class="action-menu">
        <vwc-button aria-label="Move item" size="condensed" appearance="ghost-light" class="action-menu-button draggable" slot="anchor">
          <vwc-icon name="reorder-vertical-solid" slot="icon" connotation="accent" size="-6"></vwc-icon>
        </vwc-button>
        <vwc-menu-item text="Move to top"></vwc-menu-item>
        <vwc-menu-item text="Move up"></vwc-menu-item>
        <vwc-menu-item text="Move down"></vwc-menu-item>
        <vwc-menu-item text="Move to bottom"></vwc-menu-item>
      </vwc-menu>
      <div class="content">
        <div class="text">Drag handle always visible (with drag handle button/menu)</div>
      </div>
    </div>
  </vwc-card>

  <vwc-card appearance="outlined" class="card">
    <div class="container" slot="main">
      <vwc-avatar shape="pill" connotation="cta" appearance="subtle"> <vwc-icon slot="icon" name="user-line" label="User's avatar"></vwc-icon></vwc-avatar>
      <div class="text">
        <div><b>Card</b></div>
        <div>Implied draggable</div>
      </div>
      <vwc-button id="menu-anchor" aria-label="Move item" size="super-condensed" appearance="ghost-light" class="action-menu-button" slot="anchor">
        <vwc-icon name="more-horizontal-solid" slot="icon" connotation="accent" size="-6"></vwc-icon>
      </vwc-button>
      <vwc-menu placement="bottom-start" auto-dismiss class="action-menu" anchor="menu-anchor">
        <vwc-menu-item text="Move to top"></vwc-menu-item>
        <vwc-menu-item text="Move up"></vwc-menu-item>
        <vwc-menu-item text="Move down"></vwc-menu-item>
        <vwc-menu-item text="Move to bottom"></vwc-menu-item>
      </vwc-menu>
    </div>
  </vwc-card>
</div>

<style>
  vwc-card {
    margin-bottom: 12px;
    max-inline-size: 500px;
  }

  .container {
    position: relative;
    background-color: var(--vvd-color-canvas);
    display: flex;
    align-items: center;
    padding: 8px;
    cursor: grab;

    &:hover {
      background: var(--vvd-color-neutral-50);
    }
  }

  .drag-icon {
    display: inline-block;
    margin-inline-start: 8px;
    margin-inline-end: 8px;
  }

  [draggable='true'] .container {
    cursor: grabbed;
  }

  .drop-target .container {
    background: var(--vvd-color-neutral-50);
    border: 1px dashed var(--vvd-color-neutral-300);
  }

  .drop-target .container * {
    visibility: hidden;
  }

  .content {
    display: flex;
    flex: 1;
    justify-content: space-between;
    align-items: center;
  }

  .text {
    white-space: nowrap;
    text-overflow: ellipsis;
    overflow: hidden;
    max-width: 95%;
  }

  .action-menu-button.draggable {
    --button-cursor: drag;
  }

  .card {
    inline-size: 250px;

    .container {
      padding: 8px;
      gap: 8px;
    }

    .action-menu-button {
      position: absolute;
      inset-block-start: 4px;
      inset-inline-end: 4px;
    }
  }
</style>

This pattern works well in many scenarios, but there are cases where it may not be appropriate. In those situations, decisions should be guided by what provides the best experience for people using assistive technologies.

For more complex scenarios - such as nested lists — the relevant menus should open a modal containing a form to collect any additional input required from the user.

Assistive names

• Ensure all interactive elements have meaningful names for assistive technologies.
• Accessible names for buttons should explicitly describe the action and the target element—for example, “Move task ‘clean dishes’ to top of backlog.”

Use live regions to announce content changes to screen readers. Messages in live regions will be announced by screen reader.

Live regions should provide real-time feedback both during and after an interaction. Messages should contain the name of the item being moved, as well as its old and new position.

<div id="sr-announcements" aria-live="polite">Task "Organise a team-building event" was moved from position 3 to position 8</div>

Make it easy for users to continue using the same entity after an action (where applicable). To achieve this, focus should move to the original trigger element whenever possible. This prevents someone needing to navigate back to the same spot.

If the element no longer exists after the operation, choose a new element using your best judgement.

Make it clear what can be dragged.

When drag and drop is a primary action for an element:

1. Use an always-visible drag handle icon []
   (An exception for this is when drag and drop is "implied", suc as Cards on a board)
2. Use :hover { cursor: grab }
3. Change the item’s background color on hover

When drag and drop is a secondary action for an element (eg. there are other interactive controls inside the element):

1. Use a drag handle icon that is visible on :hover or :focus-within
2. Change the background color on item hover

Make it clear what is being dragged

When an element is being dragged, its appearance should change to clearly indicate its dragged state:

1. It should appear elevated (for example, using a box-shadow) to suggest it is above other items.
2. Its background should be partially transparent so underlying elements remain visible as it is dragged over them.

Make it clear what the result will be

This is achieved using a drop target element. This is used a preview as to where the dragged element can potentially be dropped.

Drop target element

It’s appears should be different to the dragged / draggable items.

1. It should have a different background color. A light CTA shade could be appropriate.
2. It should have a dashed border in the same color variant.

These styles are inkeeping with the File Picker component’s drop target.

For sortable lists, the drop target should be the same size as the draggable items and have no visible content.

Make is clear what the user has achieved

To reinforce what the user has accomplished, the moved item’s background color should briefly flash after it has been repositioned.

This can be achieved by animating the background color from a highlight color (for example, CTA-100) back to its original value.

Next, we need to finalise the design of these states and identify what can be built into our components to ensure consistency and make implementation easier.
